Select date range to view test list for: Print this page

SQURTS Project Number: S2124SE
Test Rep.: No Volunteer

Levels: Site Specific
Tentative Test Date: 7/12/2021
Manufacturer Description Model
 DIETZ SWITCH,DIFF PRESS-0.05-8.0INWG,SPDT,10A  171D8WC-S

SQURTS Project Number: S2218SE
Test Rep.: No Volunteer

Levels: Table Limits - 14g
Tentative Test Date: 9/19/2022
Manufacturer Description Model
 cutler hammer / eaton Relay D26MRD21Y12

SQURTS Project Number: S2221SE
Test Rep.: Nasser Aly

Levels: Table Limits - 14g
Tentative Test Date: 10/24/2022
Manufacturer Description Model
 ASCO SWITCH-TRANSFER, ASCO 7000 SERIES, AUTOMATIC, 120VAC 60HZ, 30A (WCR 10kA @ 240V, 0.025sec), 2 POLE S D07ATSB20030B5XC

SQURTS Project Number: S2223SE
Test Rep.: No Volunteer

Levels: Table Limits - 14g
Tentative Test Date: 12/5/2022
Manufacturer Description Model
 Schneider Molded Case Circuit Breaker 00068489/00079287
 AMETEKPOWER TRANSMITTER-TEMPERATURE, 0 TO 225 DEG C, RESISTANCE TO CURRENT CONVERTER, 4 TO 20 mA DC RANGE, 48VDC XSC-1372-3P-A1-I1-N1-FS-C-CC [0 TO 225 DEG C]
 AMETEK POWER TRANSMITTER-., CURRENT TO DC VOLTAGE CONVERTER, 4 TO 20 MA INPUT (250 OHMS INPUT RESISTANCE) XSC-1302-ID1-V5-H1-N1-FS-C-CC
 FOXBORO/SCHNEIDER ELECTRIC SYSTEMS USA INC Temperature Transmitter (more details in file "NB Power - SQ Testing requirements" attached  RTT80-T1BBQNAZZ-D1S2
 OMEGA SIGNAL CONDITIONER MODULE SIGNAL LDX-D

SQURTS Project Number: S2226SE
Test Rep.: No Volunteer

Levels: RIM
Tentative Test Date: 12/5/2022
Manufacturer Description Model
 Farris Engineering-Curtis Wright Relief Valve 3/4 inch Inlet x 1 inch Outlet, Class 150, set at 140 psig 37DA23-M40/S4
